Ebyte NE2-D12P Single Serial Port Server Modbus gateway modes MQTTC/HTTPC IoT Gateway Mode RS232 to Ethernet serial server

NE2-D12P RS232 to Ethernet Serial Server Serial port to Ethernet serial port server ModBus gateway [Interface signal]：RS232 [Working voltage]： DC 8~28V [Network protocol]：TCP/UDP, MQTT, HTTP, IPv4, DHCP, DNS [Packaging method]： Guide rail + positioning hole installation [Product size]：80*28*27mm [Introduction]：NE2-D12P single serial port server is an isolated serial port server used to realize bidirectional transparent transmission of data from RS232 serial port to Ethernet port. It has multiple Modbus gateway modes and MQTTC/HTTPC IoT gateway modes, which can meet the networking functions of various serial port devices/PLCs; it adopts industrial-grade design standards to ensure equipment reliability. The serial port server realizes transparent transmission of serial port data to Ethernet TCP/IP data packets. Users do not need to care about the specific details, and the protocol conversion is completed inside the device. Send Inquiry Purchase File DownloadsCompare Specification Parameters Pin Definition Order Way File Downloads Series Products Project illustration working mode TCP Server(default)、TCP Client、UDP Server、UDP Client、HTTP Client、MQTT Client Socket connection TCP server supports 5 client connections network protocol TCP/UDP、MQTT、HTTP、IPv4、DHCP、DNS How to obtain IP Static IP (default), DHCP DNS domain name resolution support Domain name resolution server 114.114.114.114 (customizable) Configuration method Web page, parameter configuration tool, AT command IP address 192.168.3.7 (customizable) username admin (customizable) password admin (customizable) local port 8886 (customizable) subnet mask 255.255.255.0 (customizable) gateway 192.168.3.1 (customizable) Serial buffer 10kByte or 1024 packets Packaging mechanism Maximum 1024Byte, 1~80 bytes idle time Serial port baud rate 600~460800 bps (default 115200) data bits 5, 6, 7, 8 (default) Stop bit 1 (default), 1.5, 2 Check digit None (default), Odd, Even Working temperature and humidity -40～+85℃, 5%～95%RH (no condensation) Storage temperature and humidity -40 ~ +105℃, 5% ~ 95%RH (no condensation) Protection level Industrial EMC Level 3 Isolation voltage 1.5KV (only supported by isolated version) Electrostatic protection Contact 4KV, air 8KV burst Differential mode 1KV, common mode 2KV
