Serial RS232 / RS422 / RS485 to Ethernet Network Module ezTCP CSE-M73G
The ezTCP CSE-M73G is an embedded serial to Ethernet module with a built-in RJ45 connector for the Ethernet interface. Embedded with an optimized TCP/IP stack, it helps you simplify its implementation since it comes equipped with an RJ45 connector and serial port interface with RS232, RS422, and RS485. The CSE-M73G is a new alternative for the CSE-M73 and CSE-M73A.The CSE-M73G is especially suitable for Multi Monitoring, Solar Energy Management Systems, etc. Features: 1 x RS232/RS422/RS485, or 3.3V (5V tolerant input) 10/100Mbps Ethernet RJ45 connector embedded Compact module type (64.4mm x 40mm x 17mm) Multi-Monitoring (maximum 8 channels) Separator settings for packet fragmentation Configuration via ezManager Specifications: Serial Interface RS232 - RXD, TXD, RTS, CTS, GND3.3V level with 5V tolerant input - RXD, TXD, RTS, CTS, GNDRS422 - TX+, TX-, RX+, RX-, GNDRS485 - TRX+, TRX- , GND Connector: 1 X 6 2.54mm pitch pin header Serial Port Property Baud Rate: 300 bps ~ 230,400 bps Data Bits: 8bits, 7bits with parity Parity: None, Even, Odd, Mark, Space Stop Bit: 1, 2 (A single idle bit is automatically added to every stop bit by the MCU function.) Flow Control: None, RTS/CTS, Xon/Xoff Network Interface 10Base-T/100Base-TX Ethernet (RJ45) Ethernet Speed Auto Sense 1:1 or Cross-over Cable Auto Sense Software Functions Protocols IPv4/IPv6 dual stack, ICMPv6/TCPv6/UDPv6,TCP, UDP, IP, ICMP, ARP, TELNET, DHCP, PPPoEDNS, DDNS, Telnet COM Port Control Option(RFC 2217) Security TLS v1.2 IP & MAC filtering - Restrict host or network Password for Configuring Communication Mode TCP Server (T2S) TCP Client (COD) TCP Server/Client with AT Command (ATC) - Patent UDP Mode (U2S) Additional Functions Multi-monitoring(Max. 8 TCP connections simultaneously) TCP Server/Client Mode Sending MAC address Option Indicators (LEDs) Power: Red LAN Link/LAN RXD: Green Status/LAN TXD: Yellow Management: ezManager: Configuration and Monitoring Tool through Network and Serial Telnet: Telnet Login AT Command: Configuring in ATC mode - Patent Supplementary Software ezManager: Configuration Tool for Windows ezVSP: Serial to Network Virtual Driver for Windows ezTERM: Simple TCP/IP Communication Test Tool Dimensions Size: 64.4mm x 40mm x 17mm (2.54in x 1.57in x 0.67in) Weight: 17 Grams (0.6 Ounces) Operating Environment Input Voltage: 5VDC Current Consumption: 95mA typical Operating Temperature: -40C ~ +85C Storage Temperature: -40C ~ +85C * The above information is subject to change. Envistia Mall and Sollae Systems are not responsible for any changes. Package includes: 1X CSE-M73G ezTCP Serial Ethernet Module Delivery of evaluation quantities is stock to 2 weeks, if the item is out of stock, please contact us for availability. Documentation & Resources: EZTCP CSE-M73G Serial Ethernet Module Product Page EZTCP Utility Downloads Videos: CSE-M73 Serial Ethernet Module
