7" all-in-one Panel PC, 1024x600, Intel Core i5
Rugged 7-Inch 2nd Gen I Series Panel PC – IMD070-W200-I5 Overview The 7-inch 2nd Gen I Series Panel PC is designed for demanding industrial environments. Engineered with a robust aluminum alloy frame, it offers exceptional durability, reliability, and versatility. Featuring a fanless cooling system and an IP65-rated front panel, it ensures optimal performance in harsh conditions. Key Features Intel Core i5 processor options: I5-6200U, I5-7200U, I5-8265U, I5-10210U Ultra-slim frame optimized for embedded installations 7-inch TFT LCD with 1024×600 resolution and 300 cd/m2 brightness Capacitive or resistive touchscreen options Wide operating temperature range: -10°C to 60°C IP65-rated front panel for dust and water protection Fanless cooling system for enhanced reliability Diverse I/O ports including HDMI, VGA, USB 2.0/3.0, and LAN Built-in WiFi and optional Bluetooth connectivity Supports Windows and Linux operating systems Technical Specifications Display: 7" TFT LCD, 1024×600 resolution, 300 cd/m2 brightness, 500:1 contrast ratio Touch Screen: Capacitive or resistive options, ≥88% light transmittance Processor: Intel Core i5 with frequency options from 1.6 GHz to 2.5 GHz RAM: 4GB DDR4 (upgradable to 32GB) Storage: 128GB SSD (optional 256GB/512GB) Operating Temperature: -10°C to 60°C Dimensions: 225.04mm × 160.7mm × 59mm Power Supply: DC 12V-36V Certifications: CCC, CE, FCC, EMC, CB, ROHS Connectivity: Dual LAN (1000M adaptive), HDMI, VGA, audio I/O, and USB ports Applications Automation and control systems Manufacturing and production lines Transportation and logistics Smart kiosks and interactive terminals Oil and gas monitoring Healthcare and medical diagnostics Keywords: Industrial Screens, Customized Marine Panel PC, Winmate Panel PC, Bespoke Industrial Panel PC, HMI Monitors, Advantech Panel PC, Customizable Industrial Touchscreen PC, Industrial Terminals, Industrial Touchscreen PC, Wide Temperature Displays, Industrial Panel PC, Custom Panel PC for Retail Kiosks, Customized Fanless Panel PC, Industrial HMI Panel, Industrial Computers, Sunlight Readable Panel PC, Automation PCs, Rugged All-in-One PC Touch Screen, Custom Industrial PC for Harsh Environments, Rugged Touchscreens
