MAXKGO 15S-21S 120A BMS Protection Board Hardware Ternary Polymer Lithium Battery BMS Board
MKBMS 15-24S_120A BMS board is a full-function Li-ion battery protection board with passive balance. The continuous current can reach to 120A. It supports overcharge protection, overcharge protection, over current protection, ,over temperature protection, short circuit protection, etc. Extensive evaluation of e-bike, e-skateboard,electric motorcycles, e-scooters, electric balance cars and other fields. Parameters: wiring: same port or different ports（When using the charging and discharging port, disconnect the p-） Battery type: li-ion battery (standard voltage 3.7V) Balance method: passive balance Number of battery strings: 15S-24S Overcharge voltage: 4.25V Overcharge recovery voltage: 4.15V Over-discharge threshold: 2.8V Over-discharge release: 3.0V Passive equalization turn-on voltage: 4.125V Charging current: 80A Discharge current: 120A Charging overcurrent: 200A Discharge overcurrent: 480A Charging protection temperature: 50°C Charging recovery temperature: <45°C Discharge protection temperature: 70°C Discharge recovery temperature: <60°C Size: 140*66*16mm For detailed parameters, please refer to “15-24S BMS Parameter Table” Feature: Balance function, fully activate the battery capacity No need to adjust parameters, the operation is easier Metal heat sink, more stable performance With locking cable arrangement, the wiring is more secure Function: Over charge protection Over discharge protection Overcurrent protection Short circuit protection Temperature control protection Balanced protection Static protection Load detection function Application : Electric skateboard Electric bicycle Smart balance car Electric Scooter Forklift Cleaning car Sightseeing car Energy storage Outdoor power supply Shipping list: 1X MKBMS Li-ion BMS Board 1X GH2.0 single head P line（with buckle） Operational matters: please ensure the correctness of the wiring sequence during wiring. Please arrange the lines in order from B0-B12, B13-B24. After the battery is fully powered, the voltage will reach a maximum of 100V. There is a risk of electric shock, so please pay attention to protection.
