1.2GHz 2000mW 1600mW VTX / VRX-1G3-V2 - Long Range FPV Video Transmitter Receiver for RC Racing Drone Goggles Mateksys Matek Systems

 1.2GHz 2000mW 1600mW VTX / VRX-1G3-V2 SPECIFICATIONS Brand Name: NoEnName_Null Is Electric: No battery Origin: Mainland China Material: Plastic Recommend Age: 14+y Use: Vehicles & Remote Control Toys 1.2GHz A/V VTX Transmitter VRX Receiver 9CH 1060~1380MHz 1-1.2-1.3G 1G3 1G3SE 0.1/25/200/800mW For Long Rang DroneVTX: 1： Button control and LED indicator light 1. Four green indicator lights are power indicator lights, respectively: 0.1mW (0)/25mW(D) /200mW (C)/800mW (H), defaults to 0.1mW when turned on. Long press the button to switch Is the next power. This operation can be cycled, and the corresponding power indicator light will light up every long press and hold Start. Note: The transmission power needs to be readjusted after each power outage. 2. Nine red indicator lights are frequency point indicator lights. Short press once to switch to the next frequency point. This operation It can be cycled, and the corresponding frequency indicator light will light up every short press. Note: This operating system has a memory function, and after a power outage, the system will save the current frequency point. 2、 Interface definition: 1. The antenna is an SMA interface; The antenna head is "external thread+hole", and the antenna rod is "internal thread+ Needle "configuration with 1.2G dedicated custom" Y "shaped antenna. The sequence of connecting the 2.7P1.25 row seats is: 1. Power input DC 7-28V; 2. Input grounding; 3. Video input; 4. 6.5M audio input; 5. DC output 7-28V; 6. DC output grounding; 7. DC output 5V Frequency band: 1060~1380MHz Channel customer: 9 Channel Frequency :1080/1120/1160/1200/1240/1280/1320/1360/1258(MHz) Audio Sub-carrier: 6.5MHz/6.0MHz Modulation type :FM Input format :NTSC or PAL Input power supply :DC 7-28V Output voltage :DC7.28V ; DC5V Profile dimension :45.5mm（L）*35.8mm(W)*8.4mm(H) Installation hole position: 30.5mm x 30.5mm net weight: 10g VRX DC Characteristics） POWER SUPPLY: 5.0V Current Consumption: (280 ±40)mA Environmental Specification） RF Receiving frequency range 1050~1380MHz Voltage Standing Wave Ratio 2:1 Demodulation system FM/PLL IF 480MHz ANT. input impedance: 50Ω, Typ. Profile dimension: 44mm（L）*27mm(W)*27mm(H) net weight :20g 1500mW VTX Transmitter Voltage:DC12V Current:400mA Frequency:1.2G-1.3 Channels:8CH Connector: transmitter module side RP-SMA jack, antenna SMA plug Frequency:CH4:1080 CH5:1120 CH6:1160 HC7:1200 HC8:1240 CH9:1280 CHH:1320 CHC12:1360 Power:1500mW TRUERC SINGULARITY 1280 V2 – BLACK 1.3G Antenna Specs: Gain: 1.9dBic Cross-Polar Rejection: -15 to -30dB, (2.2%) Bandwidth:1250MHz-1290MHz Radiation Efficiency:99% SWR:<=1.5:1 Weight:x.xg Dimensions(head):40.5mm dia. X 22.5mm height. Length: xxmm Cable:RG402/RG316 coax. Connector:True-SMA ‘ certify that "Shenzhen Dolphin RC Technology Co , Ltd" have permission to advertise and resell all "TrueRC Canada products" 2W VTX Interface and key indicator layout:1. Frequency point indicator light: red LED (1 frequency point-9 frequency points)2. Power indicator light: blue LED (25mW)3. Power indicator light: green LED (2000mW/Pit mode)4. Frequency point adjustment key5. Power adjustment key6. 1.0 6P wiring socket7. MMCX antenna pedestalIV. Key control mode and LED indicator definition:1. Key ④ is the frequency point switch key; every time when key ④ is pressed for a short time to switch to the next frequency point, the corresponding red LED ① will flash, 1.2.3.4.5.6.7.8.9 in turn. The operation can be cyclic; see the following diagram for details! 2. Key ⑤ is power adjustment key and and the power will be switched to the next one every time when the key is short pressed once, cyclic between 25mW and 2000mW. The current power is 25mW when the blue LED ② is turned on; the current power is 2000mW when the green LED ③ is turned on; The key is pressed and held for 3 seconds to enter pit mode and the blue LED ② and green LED ③ will be turned on simultaneously. See the following diagram for details! Short press key to switch power; 2. Longpress thekeyto enter Pit mode 25mW 200OmW Pit mode Blue LED is tumed Green LED is Frequency Table: I. Performance and parameters:1. 1.2G 9 frequency points: (1060MHz-1380MHz);2. Maximum power: 2W (25mW/2000mW, two gears adjustable);3. Input voltage: DC 7V-36V, supporting 2-8S battery input4. Antenna interface: MMCX5. Communication protocol: IRC Tramp6. Heat-dissipating method: aluminum alloy heat sink+fan7. Mounting hole location: 30.5mm*30.5mm /ø3.15mm8. Product dimension: 37.7mm*36.1mm*11mm9. Product weight: 16gII. Product Size:
