KST Servo - DS315MG V8.0 Servo - 4.8kg / .07 Sec (4.8-8.4V DC)

KST Servo - DS315MG V8.0 Servo - 4.8kg / .07 Sec (4.8-8.4V DC) The KST DS315MG has a hardened steel drive train and a coreless motor capable of running from 4.8V to 8.4V (4 cell NiMH to 2S LiPo) meaning these servos will deliver the power and reliability you need. They are super high speed with pretty good torque. Features CNC Aluminium Case Programmable 2 Ball Bearings With 12mm Coreless Motor High Precision Metal Gear Large Stall Torque of 4.8Kg Lightweight and Compact Design Specification Item: DS315MG V8.0 Mini Servo Rated Voltage: DC6.0V Voltage Range: DC4.8V-8.4V Torque: 2.8Kgf.cm@4.8V / 3.5Kgf.cm@6.0V / 4.3Kgf.cm@7.4V / 4.8Kgf.cm@8.4V Speed: 0.10sec/60°@4.8V / 0.09sec/60°@6.0V / 0.08sec/60°@7.4V / 0.07sec/60°@8.4V Working Frequency: 1520μs/333Hz Default Travel Angle: ±70°=140° Total Temperature Range: -20℃……+65℃ Soft Start: Programmable Programmable: Yes Case Material: Aluminium Alloy Motor Type: Coreless DC Motor Gear Set Material: Hardened Steel Position Sensor: Potentiometer Ball Bearing: 2BB Case Dimensions: 23mm*12mm*27.5mm±0.2mm Weight: 20g±10% Package Including 1 * DS315MG V8.0 Servo  1 Pack of Accessories Download DS315MG Servo Technical Specification
