M5Stack Encoder Unit

$11.03
{{option.name}}: {{selected_options[option.position]}}
{{value_obj.value}}
Store Logo

RobotShop USA

View Store

Description M5Stack Encoder Unit Offers a 30-bit pulse encoding knob (30 pulses per rotation) Features two SK6812 programmable RGB LEDs Includes a 20 cm HY2.0-4P cable Suitable for scale value control/volume adjustment Interface: I2C The M5Stack Encoder Unit is a rotary encoder expansion unit with an I2C interface, integrated with a 30-bit pulse encoding knob (with button function) + 2 x SK6812 programmable RGB LEDs. The built-in STM32F030 flashed with the encoder pulse acquisition firmware, allowing users to obtain the encoded value directly via I2C. Suitable for scale value control/volume adjustment and other control scenarios. View more What's Included 1x Unit Encoder 1x HY2.0-4P cable (20 cm) Dimensions Size 32 x 24 x 22 mm Specifications Pulse encoder knob: 30-bit pulse encoder knob (with key input) Programmable RGB LED: 2x SK6812 Working current: Encoder working (DC - 5 V at 17 mA) Interface: I2C Weight: 7.4 g
