Samchully - 12", 3-Jaw, Closed Center Hydraulic Chuck, M20x2.5 - HC-12SE
thecncsource.com

Samchully - 12", 3-Jaw, Closed Center Hydraulic Chuck, M20x2.5 - HC-12SE

$3,000.00
{{option.name}}: {{selected_options[option.position]}}
{{value_obj.value}}
Store Logo

THECNCSOURCE.COM

View Store

HC-12SE [M20x2.5] Includes: Mounting Bolts; Soft Top Jaws; Master Jaws; T-Nuts; Handle Kitagawa Equivalent: N-12 Grip Dia. Max (mm): 304 Grip Dia. Min. (mm): 26 Jaw Stroke Dia. (mm): 10.5 Plunger Stroke (mm): 30 Max. Permissible Input Force [kN(kgf)]: 41 (4181) Max. Static Gripping Force [kN(kgf)]: 156 (15907) Max. r.pm.: 3380 Weight [kg]: 57.3 Series: HC Size: 12" Includes: 3 Jaws Jaws: 3 CONTACT OUR TEAM FOR AVAILABILITY PRODUCT PHOTO MAY NOT BE THE EXACT MODEL Description 12” 3-jaw, closed-12” 3-jaw, closed-center plain back hydraulic chuck with [M20x2.5] drawtube connector; 304mm O.D.; 26 ~ 304mm clamping range; 10.5mm jaw stroke on diameter; 30mm plunger stroke; 156KN maximum static gripping force; 1.5x60° master jaws serration; 3380 maximum rpm; PMAX 163
