Samchully - 12", 4-Jaw, Closed Center Hydraulic Chuck - HCF-12
$3,980.00
{{option.name}}:
{{selected_options[option.position]}}
{{value_obj.value}}
HCF-12 [M20x2.5] Includes: Mounting Bolts; Soft Top Jaws; Master Jaws; T-Nuts; Handle Weight (kg): 55 Grip Dia. Max (mm): 304 Grip Dia. Min. (mm): 26 Jaw Stroke Dia. (mm): 10.5 Plunger Stroke (mm): 30 Max. Permissible Input Force [kN(kgf)]: 27.5 (2804) Max. Static Gripping Force [kN(kgf)]: 104 (10605) Max. r.pm.: 3000 Series: HCF Size: 12" Jaws: 4 Includes: 4 Jaws CONTACT OUR TEAM FOR AVAILABILITY PRODUCT PHOTO MAY NOT BE THE EXACT MODEL Description 12” 4-jaw, closed-center plain back hydraulic chuck with [M20x2.5] drawtube connector; 304mm O.D.; 26 ~ 304mm clamping range; 10.5mm jaw stroke on diameter; 30mm plunger stroke; 104KN maximum static gripping force; 1.5x60° master jaws serration; 3000 maximum rpm
