Samchully - 12", 3-Jaw, Long-Stroke, Open-Center Chuck - HSL-12
thecncsource.com

Samchully - 12", 3-Jaw, Long-Stroke, Open-Center Chuck - HSL-12

$7,765.00
{{option.name}}: {{selected_options[option.position]}}
{{value_obj.value}}
Store Logo

THECNCSOURCE.COM

View Store

HSL-12 [BLANK] Includes: Mounting Bolts; Blank Drawnut; Soft Top Jaws; Master Jaws; T-Nuts; Handle Through-hole Dia. (mm): 63 Grip Dia. Max (mm): 304 Grip Dia. Min. (mm): 43 Jaw Stroke Dia. (mm): 36 Plunger Stroke (mm): 30 Max. Permissible Input Force [kN(kgf)]: 69.3 (7076) Max. Static Gripping Force [kN(kgf)]: 80.4 (8199) Max. r.pm.: 2200 Weight [kg]: 78 Series: HSL Size: 12" Includes: 3 Jaws Jaws: 3 CONTACT OUR TEAM FOR AVAILABILITY PRODUCT PHOTO MAY NOT BE THE EXACT MODEL Description 12" 3-jaw, long-stroke, high-speed, open-center plain back hydraulic chuck with blank draw nut; 304mm O.D.; 63mm bore; 43 ~ 304mm clamping range; 36.0mm jaw stroke on diameter; 30mm plunger stroke; 80.4KN maximum static gripping force; 1.5x60° master jaws serration; 2200 maximum rpm
