Seeedstudio RFM98 Long Range Transceiver Module 868M

Description Seeedstudio RFM98 Long Range Transceiver Module 868M Provides ultra-long range spread spectrum communication Excellent blocking immunity Built-in temperature sensor and low battery indicator. Automatic RF Sense and CAD with ultra-fast AFC. Fully integrated synthesizer with a resolution of 61 Hz The Seeedstudio RFM98 Long Range Transceiver Module 868M provides ultra-long range spread spectrum communication and high interference immunity whilst minimizing current consumption. Applications Automated Meter Reading Home and Building Automation Wireless Alarm and Security Systems Industrial Monitoring and Control Long-range Irrigation Systems View more What's Included 1x Seeedstudio RFM98 Long Range Transceiver Module 868M Dimensions Size 65 x 120 x 1.8 mm Module: 16 x 16 mm Specifications RFM98 Long Range Transceiver Modem 168 dB maximum link budget +20 dBm - 100 mW constant RF output vs V supply +14 dBm high-efficiency PA Programmable bit rate: up to 300 kbps High sensitivity: down to -148 dBm Bullet-proof front end: IIP3 = -12.5 dBm Low RX current of 10.3 mA, 200 mA register retention FSK, GFSK, MSK, GMSK,  and OOK modulation Dynamic Range RSSI: 127 dB
